Applications

The SPRINGLINE 50 CRASH FENCE is ideal for:

  • Airports
  • Sports Arenas
  • Retail Parks
  • Police Stations
  • Critical Infrastructure
  • Government Buildings
  • Conference Centres
Quick Assembley Benefits
  • Lower installation cost
  • Can be installed with a three man team
  • No special posts or fitting needed to
    change direction corners or angles or
    terminating the fence run just use the
    standard posts and fittings.
  • Once installed can enhance the fence line,
    making it into a PAS68 hostile vehicle
    mitigation fencing system.
  • Can be installed across a standard gate
    that this is only used occasionally and can
    be removed quickly for access.
  • If attacked only a short part of the fence
    will need replacing
Oneline Springline 30/50

The Worlds Most Versatile H.V.M Crash Fence Designed To Stop An Attack From Both Sides

Foundation Only 400mm Deep - Fitted & Tested in Soft Ground

Springline 50

Patent Granted

a new unique fencing system developed to protect and secure potentially vulnerable areas such as airports, government buildings, military utilities infrastructure.

THINK SAFETY (THINK) SAFETYFLEX
A New Technology breakthrough in
Shallow Mount IWA 14 Crash Fence.
Designed To Stop An Attack From Both Sides

  • AT LAST No need for deep foundations.
  • AT LAST Fitted and tested in soft ground.
  • AT LAST No heavy transport needed to move it to and from the site.
  • AT LAST No heavy plant needed to install it.
  • AT LAST The system is delivered in break down kits with ready made rebar cages if needed.
  • AT LAST Just part of the fence can be removed for access if needed.

This new generation of crash fence, has been designed to protect perimeters, from any terrorist , criminal or accidental attacks.
The IWA 14 springline 50 crash fence has been designed for hostile vehicle mitigation.
Safetyflex Barriers were commissioned to specially design a crash fence, with a very shallow foundation of only 400mm that could be installed into soft ground.
This IWA 14 springline crash fence, is designed to protect key sites, like airports, MOD Bases, oil and gas Infastruture, or any other facility that requires hostile vehicle mitigation measures along the fence line, from any vehicle attack.
The springline 50 , can be installed in short and long runs, and can stop a 7200 kg truck at 80kph.

Shallow Mount IWA 14 Crash Fence Only 400mm Foundation

CRASH FENCE SPRINGLINE 50 IWA 14 VEHICLE PERFORMANCE CLASSIFICATION

IWA 14 SPRINGLINE 50 (IWA 14-1:2013) V/7200[N3C]/80/90:8.5
Vehice Test Weight Vehicle Class Vehicle Speed kph Vehicle Angle o Vehicle Penetration m Footing Depth mm
V/7200 KG N3C 80 90 8.5 400
