Surface Mount Planters
Applications

The CRASH PLANTER 50 is ideal for:

  • Shopping Centres
  • Nuclear Sites
  • Sports Arenas
  • Police Stations
  • Airports
  • Critical Infrastructure
  • Government Buildings
  • Conference Centres
Surface Mount Planters Crash Block 50 Surface Mount Key Points

PROVIDING INSTANT H.V.M PROTECTION

The world's only high speed (BSI IWA14) Multiple Crash Tested Surface Mount Crash Planter Block:

As the growing threat of Terrorist Attacks on the public gets worse, new ways of stopping them have been developed by Safetyflex’s design team to give instant H.V.M Protection. Planter Block 50 is a surface mount block that has a special, unique design that lets the Planter Block just sit on the surface of the ground with no ground fixing. It is completely free standing and can stop a 18 tonne GVW truck travelling at 50mph/80km/h.

Four high speed impact tests were carried out on the block at (Horiba Mira) UK, vehicle impact tested centre to BSI lWA14 impact test. The first test was at 30mph/48kph at 90 degrees with a 7.5 tonne truck into the front face of the biock. The second test was 40mph/64kph at 90 degrees with a 7.5 tonne truck into the face of the block. The third test was an 18 tonne truck at 50mph/80kph at 90 degrees into the end face of the block. All tests were carried out on the same block.

BONUS TEST
The blocks were impact tested at 90 degrees into a gap of 1.2 meters between the two blocks at a speed of 30mph/48kph with a 7.5 tonne truck crashing into the gap with a result of 2.9m penetration only.

The great advantage with CRASH PLANTERS are that they can be permanent or temporary solutions as it only takes hours to install. They can also be dressed in a cladding of choice, or fitted with a planter with seating benches. All work can be done without disturbing existing ground work.

PATENT GRANTED

Want to find out more?

If you wish to find out more about the CRASH PLANTER SURFACE MOUNT then please complete our enquiry form, alternatively you can call us at +44 (0) 2476 662116 or email us on
